Backward Centrifugal Fan For High Pressure Forced Ventilation And Non-Viscous Material Conveying 9-26 Type Backward Curved Centrifugal Blower

Imagem Grande : Backward Centrifugal Fan For High Pressure Forced Ventilation And Non-Viscous Material Conveying 9-26 Type Backward Curved Centrifugal Blower

Detalhes do produto:

Lugar de origem:	Xinxiang
Marca:	ZR BLOWER
Certificação:	CE, ISO 9001
Número do modelo:	4-72 SÉRIE

Condições de Pagamento e Envio:

Quantidade de ordem mínima:	1
Preço:	50-50000
Detalhes da embalagem:	Embalagem de madeira
Tempo de entrega:	5-45DAYS
Termos de pagamento:	L/c, d/a, d/p, t/t
Habilidade da fonte:	10000

Contato

Backward Centrifugal Fan For High Pressure Forced Ventilation And Non-Viscous Material Conveying 9-26 Type Backward Curved Centrifugal Blower

descrição

Tipo:	Sopradores industriais de alta pressão	Material:	Aço, 316L, aço de /Stainless do aço carbono, Q235
Tensão:	220V/380V/440V/480V/660V	Material da lâmina:	De aço inoxidável, ferro fundido, placa de aço, (16Mn) aço de manganês Q345
Poder:	5 - 350KW	Volume de ar:	800 - 90000m3/h
Garantia:	1 ano	Cor:	Requisito do cliente
Aplicações:	Sistemas de refrigeração	Nome:	fã de fluxo axial industrial
Certificação:	CE, ISO 9001	Serviço pós-venda prestado:	Engenheiros disponíveis para máquinas de serviço no exterior, suporte online
Nome do produto:	Ventilador centrífugo da exaustão da exaustão industrial do exaustor da caldeira, fãs centrífugos in	Tamanho:	Solicitação do cliente
Recurso:	Alta eficiência	Aplicativo:	materiais do transporte e gás, planta do cimento, ventilação de exaustão, exaustão da caldeira, vent
Destacar:	backward centrifugal fan high pressure , backward curved centrifugal blower forced ventilation , 9-26 type centrifugal fan material conveying

Backward Centrifugal Fan For High Pressure Forced Ventilation And Non-Viscous Material Conveying 9-26 Type Backward Curved Centrifugal Blower

Inline duct fan Small Centrifugal Blower Fan 9-26 Type Rolling Bearings exhaust centrifugal blower cooling blower fan. 9-26 high pressure centrifugal fan is generally used for forging furnace and high pressure forced ventilation, and can be widely used for conveying materials and conveying air and non-corrosive, non-spontaneous combustion, non-viscous substances of gas.

The temperature of the medium is generally not more than 50°C (the highest is not more than 80°C), and the dust and hard particles contained in the medium are not more than 150mg/m³.

Installation Steps

Before installation, the components of 9-26 type high-pressure centrifugal fan should be comprehensively inspected, whether the rotation direction of the impeller and the casing is consistent, whether the connection of each part is firm, and whether there is any friction after the impeller rotation.
During the installation, pay attention to check that no tools and debris should be left in the shell. The connection of the inlet and outlet air pipes should be naturally consistent.
For the coupling or fan with transmission, check whether the coupling or belt wheel and belt are installed reliably.
9-26 type high pressure centrifugal fan installed, test run, can be in the fan starts must in no load adjustment door shut down the wind coming into the wind to adjust slightly open under the situation of induced draft fan for boiler.
When the 9-26 type high-pressure centrifugal fan reaches the normal speed after starting, it should be checked whether the bearing temperature is normal (generally not higher than 80°C).

Maintenance Guidelines

Only the high-pressure centrifugal fan can operate under the condition that the equipment is completely normal.
If the fan equipment is started after maintenance, it is necessary to pay attention to whether each part of the fan is normal.
Regularly remove dust, dirt and other impurities inside the fan, and prevent rust.
In order to ensure personal safety, the maintenance of the fan must be carried out during parking.

Operation Notes

In the process of starting, stopping or running the high-pressure centrifugal fan, if abnormal phenomena are found, they should be checked immediately.
In addition to the lubricant should be replaced after each maintenance, the lubricant should be replaced according to the actual situation under normal circumstances.

Key Features

Impeller diameter: 90~3500 mm

Speed of mainshaft: 560~2900 rpm

Pressure range: 3000~25425 Pa

Flow range: 1297~43305 m³/h

Air Temperature: 20~1000°C

Material: Cast Iron, Carbon Steel, Stainless Steel

Efficiency: 80%-90%

Applications

Cement

Industrial boiler

Power generation

Chemical processing

Combustion-support

Cooling systems

Corrosive gas

Dryer

Dust collection

Forced draft

Fume exhaust

General ventilation

Incineration

Induced draft
